LED Strip COB NEON 1260 / 12 VDC / 1m – Neutral White Innovative LED lighting strip made in COB technology. LED connectors were applied to the tape base at a density of 528sz / m, allowing it to obtain the effect of a continuous line of light without shining points. Self-adhesive 3M LSE mounting…
Innovative LED lighting strip made in COB technology. LED connectors were applied to the tape base at a density of 528sz / m, allowing it to obtain the effect of a continuous line of light without shining points. Self-adhesive 3M LSE mounting tape is applied to the ground. The diodes from which the tape is made are characterized by very high brightness and a wide viewing angle. Their long service life guarantees a very long, trouble-free operation. It is possible to cut the tape into shorter sections. Each segment consists of 24 diodes, and its minimum length is 45.45mm. LED strip with a substrate width of 8 mm and a length of 1m.
Make sure that the belt’s mounting location ensures proper heat dissipation, which has a huge impact on the belt’s life.
The surface on which we want to mount the tape should be properly prepared: free from dust and dirt degreased.
The tape is designed for a 12 V DC supply; there are markings on the ground that indicate how to connect it properly
power.
Note: Be careful when connecting the power supply; do not connect the tape directly to the 230V network – it may cause a risk
of electric shock and immediate damage to the product. To power the LED strips, it is recommended to use stabilized DC power supplies, maintaining a margin (reserve) of 20% of the power supply power compared to the nominal power of the tape (installation).
It is not recommended to connect LED strips in sections longer than 1m. Installations longer than 1m should be powered bilaterally or by keeping
a multiple of 5m. This will ensure rated life and eliminate voltage drops.
The IP20 protection class tapes can be used indoors in dust-free and dry conditions.
The tape can be divided into shorter sections only in places marked for cutting. Cutting the tape elsewhere will cause damage
to parts of the ground. It should be remembered that cutting the tapes can only be done with the power off.
The electrical installation in which we want to mount the LED strip must be equipped with short circuit, overload and overvoltage protections.
– (2800 – 3200 K) – 80lm/W – 950lm/m – 12VDC/14W/1m
– (4000 – 4500 K) – 90lm/W – 1050lm/m – 12VDC/14W/1m
– (6000 – 6500 K) – 90lm/W – 1050lm/m – 12VDC/14W/1m
– RGB – 12VDC/14W/1m
